High Pressure Steam Sterilizer

  • Full Automatic Sterilization Cycle
NB-SS105 / NB-SS210 / NB-SS305
Display: 7inch LCD Touchscreen

Temp. Range: 110°C ~ 135°C

Chamber Material: SUS316L

Operating System: Pre-Vacuum System

High Pressure Steam Sterilizer

Products Features

Large Capacity Horizontal Autoclave

Precision control of the chamber and jacket pressure using a digital pressure sensor and microprocessor.

Easy operation with 7” full touch LCD and user program can be set through user mode functions.

The safety of user is considered as a top priority through built-in error and alarm, safety pressure valve etc.

A self-diagnosis function can always maintain the best condition.

The most secure door lock with radial shape lever system.

Maintenance of constant sterilization temperature through automatic precision control of temperature based microprocessor.

A continuous use can be available and the thermal effect in the chamber gent larger through internal steam generation unit. (generator equipped)

Full automatic sterilization cycle of a simple structure.

Specification

NB-SS105 NB-SS210 NB-SS305
Overall Size 685(W)x1300(D)x1480(H)mm 740(W)x1400(D)x1600(H)mm 800(W)x1400(D)x1650(H)mm
Chamber Size 420Ø(diameter)x760(D)mm 520Ø(diameter)x1000(D)mm 500(W)x1000(D)x610(H)mm
Chamber Volume 105 liters 210 liters 305 liters
Chamber Material SUS316L SUS316L SUS316L
Shelf Size 210(W)x720(D)mm / 1ea 240(W)x960(D)mm / 1ea 460(W)x900(D)mm / 2ea
Temperature Range 110°C ~ 135°C 110°C ~ 135°C 110°C ~ 135°C
Control System Micro Processor Micro Processor Micro Processor
Dry System Vacuum Pump OR Steam Ejector Vacuum Pump OR Steam Ejector Steam Ejector
Operating System Pre-Vacuum System Pre-Vacuum System Pre-Vacuum System
Power Consumption Single AC220V and 9kW 3P AC220V/380V, 50/60Hz Single AC220V and 11kW 3P AC220V/380V, 50/60Hz AC220V, 3ph, 50/60Hz, 18kW Or AC380V, 3ph, 4wire, 50/60Hz
Weight 320kg 460kg 710kg
Accessory Thermal Printer(Option)
