How to use Integrated Stem Cell Workstation
Features
- General centrifuge, cooling centrifuge.
It’s designed for multi-purpose such is isolating cell or blood. 12ea of standard tubes (50 ml) can be rotated at one time.
- Shaking incubator.
Shaking incubator is used to mix or incubate sample with medium after centrifugation. Temperature and PRM can be adjusted through the waterproof control panel.
- Bio-Work Station.
99.99% HEPA Filter and UV sterilization provide pure environment. Air circulation can be regulated to be strong or weak. The air connection is laminar flow type (Air curtain) to cut it off from the external environment.
- Foot Switch.
It is designed to start & stop Centrifuge and Shaking Incubator by foot
- Hepa Filter.
It’s equipped to filter 99.99% of particles over the size of O.3╗m.
- Pressure Gauge.
By checking the pressure gauge which indicates internal air pressure, it allows you to notice the filter defects as well as the timing of replacing the filter.
- Customization Option.
Customize your Multi Station with your desired device to be inserted in this work station.
Main Specifications
| ITEMS | NB-803MS | NB-803MSF |
|---|---|---|
| Centrifuge Max RPM | 5000 RPM | 5500 RPM |
| Max Force | 4612xg | 5580xg |
| Max Capacity (ml) | 480ml, 15mlx32Tubes (Swing rotor) | 480ml, 15mlx32Tubes (Swing rotor) |
SHAKING INCUBATOR |
||
| Temp range (°C) | Amb +5°C~60°C | Amb +5°C~60°C |
| Speed Range (rpm) | 30~300 rpm | 30~300 rpm |
DIMENSIONS |
||
| Work space (mm) | 900x640x620(H) mm | 1200x600x620(H) mm |
| Overall (mm) | 900x790x1920(H) mm | 1200x825x1920(H) mm |
| Power (V/Hz) | 110/220V, 50/60Hz, 800W | 110/220V, 50/60Hz, 1.2kW |
